- Brand: Hikvision
- Model: DS-2CD1T67G3-LIUF/SL
- Type: Surveillance Camera
-
Camera
- Image Sensor: 1/2.4" Progressive Scan CMOS
- Resolution: Max. 6MP, 3200 × 1800
-
Illumination: Min. Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux With Light
- Shutter Time: 1 s to 1/100,000 s
- Day/Night: IR Cut Filter
- Angle Adjustment: Pan: 0° to 360°,Tilt: 0° to 180°,Rotate: 0° to 360°
- Lens: 4mm, Fixed Focal Lens
-
Field of View: Horizontal FOV 89°, Vertical FOV 49°, Diagonal FOV 105°
- Lens Mount: M12
- Light Type: IR, White Light
- Light Range: Up to 50m
- IR Wavelength: 850nm
- Day/Night Switch: Day, Night, Auto, Schedule
- Support WDR: Yes
- Image Enhancement: BLC,HLC,3D DNR
-
Video & Audio
- Main Stream: 50Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720), 60Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream: 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360), 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
-
Video Compression: Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
-
Video Bit Rate: 32 Kbps to 16 Mbps
- Environment Noise Filtering: Yes
-
Interface
- Built-in Mic: Yes
- Ethernet Interface: 1x RJ45 10 M/100 M Self-Adaptive Ethernet Port
-
Network
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP, UPnP
-
Simultaneous Live View: Up to 6 Channels
-
API: Yes
- User/Host: Up To 32 Users, 3 User Levels: Administrator, Operator, and User
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP, UPnP
-
General
- Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or Less (Non-Condensing)
- Protection Level: IP67
- Power Supply: 12 VDC ± 25%
- Power Consumption: Max. 8.8W, PoE: IEEE 802.3af, Class 3, Max. 10.7W
- Material: Metal, Plastic
- Dimensions: 81 × 83.7 ×211mm
- Weight: 520g
- Warranty: 1 Year With Warranty Of The Authorized Agent
