$21.97
Original: $62.78
-65%Hikvision IDS-7108HQHI-M1/S FHD DVR 8CH—
$62.78
$21.97The Story
- Brand: Hikvision
- Model: IDS-7108HQHI-M1/S
- Type: DVR
-
Video & Audio
- IP Video Input: 2-ch (up to 10-ch), Up to 6 MP Resolution
- Analog Video Input: 8-ch BNC Interface (1.0 VP-P, 75 Ω), Supporting Coaxitron Connection
- Video Live: 4MP
- Video Recording: 1080P
- Video Input Types: HDTVI/AHD/CVI/CVBS/IP
- VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Audio Input: 1-ch RCA (2.0 Vp-p, 1 KΩ) - 8-ch via coaxial cable
- Audio Output: 1-ch, RCA (Linear, 1 KΩ)
-
Recording
- Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
-
Frame Rate: Main Stream: When 1080p Lite mode not enabled: 3K lite@12fps; 4 MP lite/1080p@15fps; 720p/WD1/4CIF/VGA/CIF
@20fps, When 1080p Lite mode enabled: 3K lite/5 MP lite@12fps; 4 MP lite@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps
(P)/30fps (N) ,Sub Stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) - Video Bitrate: 32 Kbps to 6 Mbps
- Stream Type: Video, Video & Audio
- Audio Bitrate: 64 Kbps
-
Network
- Network Interface: 1x RJ45 10/100 Mbps Self-adaptive Ethernet
- Total Bandwidth: 96 Mbps
- Remote Connection: 64
-
Interface
- HDD Type: 1x SATA
- Capacity: Up to 10TB Capacity for Each Disk
- USB: Rear Panel: 2× USB 2.0
-
General
- Operating Temperature: -10 °C to 55 °C (14 °F to +131 °F)
- Operating Humidity: 10% to 90%
- Power Supply: 12 VDC, 1.33 A
- Power Consumption: ≤ 12 W (Without HDD)
-
Dimensions (W × D × H): 200 x 200 x 48mm
- Weight: ≤ 1 kg
- Warranty: 1 Year With Warranty Of The Authorized Agent
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
- Brand: Hikvision
- Model: IDS-7108HQHI-M1/S
- Type: DVR
-
Video & Audio
- IP Video Input: 2-ch (up to 10-ch), Up to 6 MP Resolution
- Analog Video Input: 8-ch BNC Interface (1.0 VP-P, 75 Ω), Supporting Coaxitron Connection
- Video Live: 4MP
- Video Recording: 1080P
- Video Input Types: HDTVI/AHD/CVI/CVBS/IP
- VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Audio Input: 1-ch RCA (2.0 Vp-p, 1 KΩ) - 8-ch via coaxial cable
- Audio Output: 1-ch, RCA (Linear, 1 KΩ)
-
Recording
- Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
-
Frame Rate: Main Stream: When 1080p Lite mode not enabled: 3K lite@12fps; 4 MP lite/1080p@15fps; 720p/WD1/4CIF/VGA/CIF
@20fps, When 1080p Lite mode enabled: 3K lite/5 MP lite@12fps; 4 MP lite@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps
(P)/30fps (N) ,Sub Stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) - Video Bitrate: 32 Kbps to 6 Mbps
- Stream Type: Video, Video & Audio
- Audio Bitrate: 64 Kbps
-
Network
- Network Interface: 1x RJ45 10/100 Mbps Self-adaptive Ethernet
- Total Bandwidth: 96 Mbps
- Remote Connection: 64
-
Interface
- HDD Type: 1x SATA
- Capacity: Up to 10TB Capacity for Each Disk
- USB: Rear Panel: 2× USB 2.0
-
General
- Operating Temperature: -10 °C to 55 °C (14 °F to +131 °F)
- Operating Humidity: 10% to 90%
- Power Supply: 12 VDC, 1.33 A
- Power Consumption: ≤ 12 W (Without HDD)
-
Dimensions (W × D × H): 200 x 200 x 48mm
- Weight: ≤ 1 kg
- Warranty: 1 Year With Warranty Of The Authorized Agent
